Reson SeaBat 7125 Multibeam Hydrographic Surveying and Side Scan Sonar System

Below are some data samples from Sebastion Inlet using the 7125 Multibeam SeaBat.

Shown below are Multibeam survey images of pipeline retrieved while doing an inspection survey in The Gulf of Mexico with high definition side scan sonar, multibeam survey, ROV and divers. See more of this job on our experience timeline.

Multibeam Images of Pipeline

Teledyne Reson SeaBat T50

Land & Sea Surveying remains at the forefront of surveying technology. The latest and greatest of our technology is the Teledyne Reson Seabat T50. The Seabat T50 is designed for shallow water surveys.  Combined with the Portable Sonar Processor, the SeaBat T50 provides unprecedented survey data, providing faster operational surveys and reduced processing time. The T50 is designed for fast mobilization on smaller vessels. This equipment is fully frequency agile from 190 to 420 kHz, allowing for improved swath performance and reduced survey time under challenging conditions. It is capable of bathymetry, snippets, side-scan and water column backscatter, compressed water column, normalized backscatter; 7K data format; Gbit Ethernet.

Here are some examples of Reson SeaBat T50  collected data in Lhoist Lowell Quarry.

These are from Cocoa Grand Borrow Pit; bottom left shows an old sunken crane at the bottom of the pit.

Applanix POS MV Oceanmaster & Surfmaster GPS/Inertial Measurement Units

IP 68 IMU- no export restrictions
Measures heading, roll, pitch and all latitudes and dynamic conditions
Instantaneous reaquisition of RTK following GPS signal loss
 Superior low elevation tracking perfomance reguardless of latitude

The Applanix POS is a navigation system that is used to provide accurate attitude, heading, heave, position, and velocity data of our vessel and other onboard sensors while surveying.

Geometrics G-882 Marine Magnetometer

MagLog Lite software to log, display and print GPS positioned measurement results
Particularly well-suited for the detection and mapping of all sizes of ferrous objects, including anchors, chains, cables, pipelines, ballast stone and other scattered shipwreck debris, and any other object with magnetic expression
Uses Ashtech Proflex 500 Network RTK GPS for positioning

EdgeTech  Full Spectrum SB-216S, 3100 Portable Sub-Bottom Profiler

The EdgeTech Sub-bottom Profiling System is a wideband Frequency Modulated (FM) sub-bottom profiler utilizing Edge Tech's  Full Spectrum CHIRP technology. The system generates high-resolution images of the sub-bottom stratigraphy in oceans, lakes, and rivers. Sub-bottom profiling systems are used to determine physical properties of the sea floor and to image and characterise geological information below the sea floor.

Just above are Sub-Bottom Profile reports.

Edgetech 4125 Side Scan Sonar

EdgeTech’s 4125 Side Scan Sonar System was designed with both the Search & Recovery (SAR) and shallow water survey needs in mind. The 4125 utilizes EdgeTech’s Full Spectrum CHIRP technology, which provides higher resolution imagery at ranges up to 50% greater than non CHIRP systems operating at the same frequency. This translates into more accurate results and faster surveys, thus cutting down on costs.  The 600/1600 kHz set is ideally suited for ultra high resolution imagery in order to detect very small targets (SAR).

Ultra high resolution imagery for easier identification of targets
Lightweight for one person deployment
Dual simultaneous frequencies
600/1600 kHz towfish
Standard heading, pitch, roll and depth sensors
Topside processor and laptop for open boat operations
Sets up in minutes and is easy to operate
Optional quick change tow bracket for hull inspections
System is supplied in rugged portable cases for easy transport

Just above are side scan sonar data of oyster beds.

Side Scan Sonar Images of Exposed Pipelines

 Mesotech MS 1000 Scanning Sonar

Simultaneous multiple scanning sonar head and altimeter operation, and sensor configurations
Time-tagged recording of all sonar and sensor inputs to the PC’s hard-drive or external recording device
Advanced target measurement and annotation tools
Track Plotter module allowing the user to pre-plot search and survey lines, and to geo-reference sonar targets
Ping synchronization for multiple-head operation; fused data display for dual head profiling
GeoTiff image format
3D profiling with pan device
Plug-and-play USB keypad

Teledyne Odom Echotrac VC-100

The Echotrac is a singlebeam system that can be transferred between vessels to collect bathymetric data in various conditions and water depths.

Dual frequency transducer 33/200kHz
Depth range 20cm (0.8 ft) to 300m (1,000 ft)
Lightweight – 5kg (11lbs)
Desktop or bulkhead mountable
Rugged and waterproof
Suitable for autonomous vessels
DSP digitizer with manual filter control
Calibration menu with controls for transducer draft and index plus sound velocity and bar depth controls

Gladius Mini Underwater ROV Drone

The new ROV mini drone is small, compact and is utilized for underwater surveying.  This underwater drone can dive to 330 feet. It is equipped with a camera that can capture UHD 4K and Full HD video, and it can also capture 12-megapixel stills. On both sides of the camera are adjustable 1200-lumen LED headlights with a continuous-power dial on the controller. The battery and 64GB SDXC card are sealed in the vehicle. We attach a smart phone or tablet to the remote control, and the base station creates a Wi-Fi signal that allows the remote control to position the vehicle in the water which allows us to see what the camera is seeing on the smart phone or tablet with the specified app.

Two Specialty Devices Singlebeam Hydrographic Survey Systems:

Intelligent Depth Sounder that digitizes the echo to 16 bit resolution and stores the full digital record on hard disk
Sounding ranges to 200 meters with accuracy to one centimeter
DepthPro Software and Depthpic Software provide convenient replay and reprocessing of hydrographic data.
DGPS and DGPS Reference Subsystems— 24 channel receivers and RTK for sub-centimeter accuracy
Navigation Computer Subsystem— dedicated Intel Pentium Computer with HYPACK 2010 software for navigation and post-processing
RTK Driven Navigation with 200 kHz and 28 kHz transducers
Positions, events and operator annotations are exchanged between HYPACK and SDIDEPTH
Ashtech ProFlex 500 RTK GPS unit with antenna and receiver which feeds into the HYPACK software to provide horizontal and vertical positioning, eliminating the need for a tide station. The increased accuracy in using this system is most evident in areas of extreme tidal variations.

SonTek CastAway-CTD

The CastAway-CTD is a small, rugged and technically advanced CTD designed for profiling to depths of up to 100m.This  system incorporates modern technical features which allow it to achieve a 5 Hz response time, fine spatial resolution and high accuracy. It uses a six electrode flow-through conductivity cell with zero external field coupled with a rapid response thermistor to attain high measurement accuracies.  Each CastAway-CTD cast is referenced with both time and location using its built-in GPS receiver. Latitude and longitude are acquired both before and after each profile. Plots of conductivity, temperature, salinity and sound speed versus depth can be viewed immediately on the CastAway's integrated color LCD screen in the field.

Handheld castable instrument that provides instantaneous profiles of temperature, salinity and sound speed
Integrated GPS position
Wireless data transfer
5 Hz sampling rate
Temperature Accuracy: 0.05°C/Salinity Accuracy: 0.05°C
INtegrated with HYPACK

Vibracore

Vibracoring is a sediment sampling technology to obtain undisturbed cores of sediment in saturated or nearly saturated conditions by driving sampling tubes with a high-frequency-low-amplitude vibrating device. During sediment coring, the high-frequency vibration transfers the energy to the sediment and aids in the liquefaction of the surrounding sediment.

Specifications:

High frequency vibration acquires near undisturbed cores
Ideal sampler for sediment geophysical parameters, contaminants, and trace metals
Unique near zero “core compression” for accurate true depth of sample recovery
30 foot long core samples from up to 350 foot water depths
Designed for small boat operation. Powered by two 12 volt batteries
Core Keepers in Stainless Steel or Aluminum available for very soft or coarse sand sediments
Integral “floating” top vent and seal helps collect very soft sediment samples
Unique, power saving “Energy Storage” weight ring design increases effectiveness
Quick-change and long-life core tube mount makes core tube mounting a simple operation
Simple, safe low-voltage car battery power, no generator or compressor needed on a small boat

Here is a sample Vibracore Report shown below...

Above is a picture of the sediment sample pulled from Sykes Creek in Merritt Island.

AGA Divatory Masks

These Divatory masks are great when surveying and doing jobs in difficult conditions such as extremely cold, rough and/or unclear water. The breathung valve is balanced and maintains extremely low breathing resistance at all diving depths even if variations occur in the secondary pressure.

Meets performance requirements of EN 250.
High Air flow capacity and low breathung resistance increases our diving performance and endurance
Leakiage is prevented by a double sealing on the exhalation valve
Low dead space volume (air consumption and C02 build up is minimal)
Designed for use in cold-water dives.
Fully functional in (air)
Temperature range of: -30 to +70C° / -22°F to +158°F
Medium pressure range: 5-11 bar / 72-160 psi
Safety valve (built in feature)
Opening pressure: 12-20 bar / 174-290 psi 160 x 110 x 230 mm
